12mm Pot + Sw 14


	Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Part Number

3RP/125


	Select Part Numbers from the table then click on the “Request a Quote” Button to send your requirements for Price and Delivery. If you need custom product please use the “Send your Specs” Button

Electrical Characterisics

Mechanical Characteristics

Resistance Values

5 KOhm ~ 500 KOhm +/- 20%

Total Rotational Angle

Outer shaft = 120 deg
Inner shaft = 300 deg

Resistance Taper

A, B, C

Rotational Torque

30 ~ 250 gf/cm

Residual Resistance

0.1% max of total resistance

Rotational Stop Strength

Outer shaft = 4 kgf/cm
Inner shaft = 5 kgf/cm

Rated Power

0.05W

Push / Pull Strength

5 kgf/cm

Operating Voltage

taper A, C = 50V
taper B = 100V

Click Position

0 / Center

Insulation Resistance

100MOhm min @500V DC

Click Torque

60 ~ 450 gf/cm

Gang Error

3dB max

LIfe

10,000 cycles

Type Of Bushing

bushing = M7x0.75

CODE

A

DIM “ML-”

7.0

bushing = M9x0.75

CODE

D

E

DIM “ML”

7.0

26.0

Type Of Shaft

FOR BUSHING CODES “A” & “D”

CODE

A

B

C

LENGTH

15.0

20.0

25.0

DIM “F”

7.0

12.0

12.0

BUSHING CODE

A, D

E

CODE

2

3

4

5

1

LENGTH

15.0

20.0

25.0

30.0

41.0

DIM “T”

6.0

10.0

12.0

12.0

8.0

DIM “M”

0.5

1.0

2.0

2.0

4.0
